505552 3/16-in x 1/4-in x 250 ft PVC Coated Galvanised Steel 7 x 19 Aircraft Cable Metal Wire Rope with 850 lb Safe Working Load
Product details
| Management number | 211765658 | Release Date | 2026/04/04 | List Price | $30.42 | Model Number | 211765658 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
CableType: Galvanized - Vinyl-Coated Construction: 7x19 Diameter: 3/16 x 1/4-inch (6.35mm) (Cable x Overall Diameter) Length: 250-feet safe work load: 740 lbs (335 kg) Packaging: Reel KingChain vinyl-coated galvanized aircraft cables are used for many material handling applications and have typical home uses for garage door cables, winch lines, tie-downs, dog runs, hanging signs, and guy wires for flagpoles. KingChain aircraft cable is made in accordance with US Federal Specification RR-W-410D. The cable is hot-dipped galvanized for long lasting durability and moderate corrosion resistance. The 7x19 construction consists of 19 individual wires laid in a spiral around a center "King" wire to form a strand. Seven strands are then wound together to form a cable. The cable is then coated in a clear sheath of vinyl for added weather resistance. This construction provides superior strength, flexibility and abrasion resistance compared to 7x7 cable. Remove sections of the vinyl coating when using cable accessories, like sleeves, clips or thimbles. The steel cable must be in contact with the accessory to ensure a secure grip. This cable has a Safe Working Load (SWL) of 850 lbs (386 kg). Its breaking strength is 5 times the SWL (design factor 5:1). Any breaking strength ratings are listed for comparison purposes only. Actual operating loads may vary but should not exceed the recommended design factor of 20% of the products breaking strength. Not intended for aircraft use.
- 850 lbs (386 kg) safe work load (SWL)
- 3/16" cable diameter
- Galvanized finish provides good corrosion and rust resistance
- 4-3/4" throat depth (12cm)
- 1/4" overall diameter, 7x19 construction
| UPC | 066366505559 |
|---|---|
| Color | silver |
| Material | Alloy Steel, Polyvinyl Chloride |
| Item Form | Coil |
| Brand Name | KingChain |
| Item Shape | Round Rod |
| Unit Count | 1.0 Count |
| Finish Type | Polished |
| Item Weight | 19.1 Pounds |
| Part Number | 505552 |
| Grade Rating | Commercial |
| Manufacturer | KingChain |
| Model Number | 505552 |
| Item Diameter | 0.19 Inches |
| Item Thickness | 4.76 Millimeters |
| Item Type Name | 505552 PVC-Coated Galvanized Aircraft Cable |
| Item Dimensions | 8 x 8 x 5.5 inches |
| Number of Items | 1 |
| Tensile Strength | 12000 Pounds Per Square Inch |
| Included Components | 1 REEL |
| Recommended Uses For Product | garage door cables, winch lines, tie-downs, dog runs, hanging signs, guy wires for flagpoles |
| Global Trade Identification Number | 00066366505559 |
